Product Features:

• Dual-Path Communication (Ethernet/IP + LTE Cellular) - Provides reliable, redundant alarm reporting through secured and supervised multi-carrier SIM cellular, Wi-Fi®, and Ethernet channels.
• Multi-Frequency Wireless Receiver (319/345/433 MHz) - Compatible with legacy sensors from GE, Qolsys, 2GIG, Honeywell, and DSC, allowing reuse of existing hardware for cost-effective upgrades.
• Integrated Z-Wave® Automation Hub - Controls lighting, door locks, thermostats, and smart devices directly from the Touchpad Pro or the Alula Interactive App.
• Touchpad Pro Keypad (RE667X-PRO) - Features a sleek touchscreen interface with audible notifications for arming/disarming, zone status, environmental alerts, and Z-Wave® activity.
• Complete Starter Kit - Includes (3) DWS-LL LongLife Door/Window Sensors, (1) RE611P Wireless PIR Motion Detector, and a Touchpad Pro Keypad.
• Integrated Sensor Translator - Enables smooth takeovers and retrofits, supporting a wide variety of third-party sensors across multiple frequency bands.
• Long-Range Encrypted Wireless Receiver - Ensures secure, extended coverage for large residential, commercial, or multi-unit environments.
• Eight Partition Capability - Protect multiple zones or buildings under one unified system - ideal for apartments, offices, and multi-structure sites.
• Local Programming and Setup - Configure zones, users, and automation settings directly on the Touchpad - no laptop or tablet required.
• Alula Doorbell Camera Integration - Supports live two-way audio communication with visitors via the Touchpad Pro or mobile app.
• Flexible Installation - Wireless arming and mobile control eliminate the need for mounting the panel near an entry door.
• Expandable and Scalable - Supports additional Alula sensors, communicators, and automation modules for future system growth.
• Secure, Encrypted Communication - Built on Alula's proven Connect+ platform for advanced encryption and tamper protection.
• GeoArm Monitoring Options - Choose between 24/7 Professional Central Station Monitoring or DIY Self-Monitoring through the Alula Interactive App.

CONNECT-FLX Panel/Communicator

Physical

• Housing Dimensions: 6 x 6 x1.28 in (15.21 x 15.21 x 3.25 cm)
• Weight: 16.5 Ounces (467 grams)
• Mounting Fastener: #6 or #8 screws (included)

Environment

• Operating Temperature: 32 to 120°F (0 to 49°C)
• Storage Temperature: -4 to 86°F (-20 to 30°C)
• Maximum Humidity: 85% non-condensing relative humidity

Device Specifications

• Communication: Cellular, Wi-Fi®, Ethernet
• Users: 50 Users
• Zones: 96
• Partitions: 8
• Interface Devices: Up to 4 Touchpads, up to 8 PINPads
• Sensor Frequencies: 433.92MHz, 345MHz, 319.5MHz
• Power Supply Number: 12V Input Provided: RE012-6(W) (US)
• Battery Part Number: RE029
• Battery Backup: 24 hours
• Tamper Indications Sensors: Cover opening, wall removal

Certifications

• CONNECT-FLX: UL 985, UL 1023, UL 2610 FCC, IC ULC-S304, ULC-S545
• Warranty: 5 years

RE667X-PRO Touchscreen Keypad

• Wall-Mount Dimensions: 4.27" x 7.42" x 1.60" in
• Tabletop Stand Dimensions: 3.60" x 7.42" x 4.58" in
• Weight: 20.64 oz
• Color: White
• Pilot Hole for Screw into Wood: 1/8in (3mm)
• Pilot Hole for Wall Anchor: 3/16in (4.7mm)
• Mounting Fasteners: #6 screws & 4 wall anchors (included)
• Operating Temperature: 32°F to 120°F (0°C to 49°C)
• Maximum Humidity: 85% non-condensing relative humidity
• Battery Life: 4 hours
• Power Transformer Input: 100-240V AC, 50/60Hz, 0.5A
• Power Transformer Output: 12VDC, 1A
• Power Transformer Part Number: RE012-6
• Terminal Block Wire Gauge: 16-24 AWG
• Wireless Range: 300 feet in open air
• Screen Resolution: 1024 x 600 pixels
• Screen Size: 7 inches diagonally
• WiFi DeviceLink: RE926RX Not Included (only needed for Connect+)
• Certification: FCC, IC, RCM

DWS-LL Door/Window Contacts

• Housing Dimensions: 2.90 x 1.04 x 0.39 inches (7.4 x 2.6 x 1.0 cm)
• Weight with Battery: 0.79 ounces (22.5 grams)
• Mounting Fastener: High Bond Tape (3M VHB Tape)
• Operating Temperature: 32 to 120°F (0 to 49°C)
• Maximum Humidity: 85% non-condensing relative humidity
• Frequency: 433.92 MHz
• Replacement Battery: One Panasonic CR2032
• Nominal Battery Life: 10 years
• Battery Voltage: 3.0 VDC (Nominal)
• Current Draw: 20 mA (Maximum), 0.5 uA (Quiescent)
• Transmitted Indications: Cover Tamper, Low Battery, Supervision
• Certification: FCC, IC

RE611P PIR Motion Detector

Physical

• Dimensions: 3.50 x 2.40 x 1.70 inches (8.9 x 6.1 x 4.3 cm)
• Weight with Battery: 3.2 ounces (91 grams)
• Mounting Fasteners: 3M VHB (Very High Bond) Tape or Screws (both provided)

Environmental

• Operating Temperature: 32 to 120°F (0 to 49°C)
• Maximum Humidity: 85% non-condensing relative humidity

Sensor Specifications

• Frequency: 433.92 MHz
• Pet Immunity: Up to a maximum of 85 lbs.
• Replacement Battery: One Panasonic CR132A
• Nominal Battery Life: 5 years
• Battery Voltage: 3.0 VDC (Nominal)
• Optimal Mounting Height: 7.5 feet (2.3 m)
• Transmitted Indications: Cover Tamper, Low Battery, Supervision
• Certification: FCC, IC
