ADC-V700X - Outdoor Day/Night IP Security Camera

ADC-V700X - Outdoor Day/Night IP Security Camera
Please Note: The ADC-V700X outdoor day/night IP security camera has been discontinued without replacement. Standalone Video Surveillance:
Unlike other video surveillance solutions, this wired outdoor security camera does not need a digital video recorder (DVR). The only requirement is power and broadband internet service at the location where you plan on mounting the outdoor security camera. The recorded video gets stored securely offsite in the Operations Center so there is never a threat of video being destroyed onsite. With standalone video surveillance you would be able to remotely log in from a computer, PDA, or cell phone to view live video footage or recorded clips and receive notification of new recorded video.

ADC-V700X Outdoor Day/Night IP Wired Security Camera Product Description:
This outdoor day/night wired security camera can be used as a standalone video surveillance system, or it can be integrated with a GE Simon XT Wireless Security System when you choose GeoArm's interactive alarm monitoring service. Interactive monitoring with video surveillance allows you to look in live to your property anytime and anywhere as long as you have a web enabled PDA, cell phone, or computer. You also would have the ability to record video whenever an alarm occurs or the outdoor security camera detects motion. Unlike an expensive traditional digital video recorder (DVR) surveillance system which stores its data on site, the ADC-V700X transmits its data to an offsite remote location ensuring the security of your recordings.

The ADC-V700X captures color video at up to 640 x 480 resolution while providing for (0) lux low-light sensitivity and adjustable video motion detection. The wired outdoor security camera is also weatherproof and can operate between -4° and 122° F and up to 90% relative humidity. Unlike the indoor wireless IP security cameras, this wired outdoor security camera does need a hardwired broadband internet connection. (An ethernet cable is not included with this camera.) Plug this outdoor security camera into a standard A/C wall outlet and, with an active hardwired internet connection, you are ready to view live video from anywhere. You also can add a 9' power extension cable if there isn't an outlet near where you want to mount the outdoor security camera.

ADC-V700X Outdoor Day/Night IP Wired Security Camera Power-Over-Ethernet:
With a power-over-Ethernet (PoE) injector, you would not need to use the camera's AC power adapter. The camera would get its power through the ethernet cable that is already required for the broadband internet signal. The PoE injector installs at the router and provides the power needed for the camera. Since it is hard to find an A/C wall outlet outside where you are mounting the camera, this can greatly simplify the installation of an ADC-V700X.

ADC-V700X Outdoor Day/Night IP Wired Security Camera Free Custom Programming: Custom security system programming is FREE for all GeoArm monitored clients.

ADC-V700X Outdoor Day/Night IP Wired Security Camera Features:
  • Access live and recorded video clips via the internet using iPhone, Blackberry, Android or other supported mobile device
  • View live video from one or more of the cameras simultaneously
  • Receive alerts with optional video attachments whenever new video is recorded
  • Customize recording settings based on events, video motion detection, or time of day
  • Record and store video securely on's remote servers (no local DVR or computer required)
  • Cameras are weatherproof and day/night capable (0 lux low-light sensitivity)
ADC-V700X Outdoor Day/Night IP Wired Camera

Dimensions (D x W x H) 27.94 x 88.9 (mm), 5.9 x 2.3 x 2.3 (in)
Weight 22.2oz (629.36g)
Live Resolution Options 640x480, 320x240, 176x144
Recording Resolution Options 640x480, 320x240
Operating Environment -4° to 122°F (-20° to 50°C)
Live Quality High, Medium and Low compression options
Recording Quality High, Medium and Low compression options
Recording Compression MPEG-4
Image Sensor ¼” CMOS, Progressive Scan
Iris Fixed, f=4.0mm, F1.8
Field of View 56° x 42° (Horizontal x Vertical)
Low-light sensitivity 0lux at F1.8 (IR LED on)
Image Adjustments Brightness, Contrast, Saturation, Sharpness, Exposure
Video Motion Detection 3 Windows, Adjustable sensitivity and threshold
Digital Input Trigger Yes
Ethernet connection 10/100Mbps RJ-45
Password Authentication ”Digest” authentication
Simultaneous Viewers 5
Weatherproof Yes (IP66)
Operating Humidity 90% relative humidity
Max Power Consumption 12VDC or 24VAC at 500mA
802.3af PoE compliant Yes

ADC-V700X Outdoor Day/Night IP Wired Security Camera PDFs for Additional Information:
Data Sheet for's Outdoor Day/Night Wired Security Camera (ADC-V700X)
Technical Specifications for's Outdoor Day/Night Wired Security Camera (ADC-V700X)
Brochure for's Video Surveillance Service
FAQ for's Video Surveillance Service Security Cameras require Broadband Internet Service.
For Advanced Router Configurations, you may need to Contact your Network Administrator.
