GeoWFD - GeoAlarm Wireless Flood and Freeze Detector

GeoWFD - GeoAlarm Wireless Flood and Freeze Detector
GeoWFD - GeoAlarm Wireless Flood and Freeze Detector
Item# GEO-WFD

Average Customer Rating:
Read Review(s) | Write a Review

List Price: $31.47
Your Price: $20.98
Availability: In Stock
QTY:

GeoWFD Product Description:


The GeoWFD is a wireless 433 MHz encrypted flood/freeze sensor which protects against costly water or temperature related damage. The GeoWFD detector is designed for indoor residential and light commercial use. When a flood or freeze alarm is triggered, the detector will then transmit an alarm notification to the GeoAlarm control panel (GeoCP), end-user, and/or GeoArm central monitoring station informing everyone selected of an alarm initiating event. The GeoWFD is easily installed under sinks, near showers, tubs, toilets, dishwashers, fridge, washing machines, water heaters, basements, and other areas where water may accumulate or pool.

Product Features:

  • Encrypted 433 MHz Wireless Sensor
  • Detects wet, dry (Loop 1) or freeze (Loop 2) conditions
  • Transmits Tamper and Low Battery Alarms
  • Compatible with GeoAlarm smart security and automation panel

GeoWFD Product Specifications:


  • Dimensions (Diameter x Height): 2.48 x 0.69 in. (62.99 x 17.53 mm)
  • Wireless Signal Range (Sub-GHz Distance): 110 m (Open Area)
  • Sub GHz Modulation: OOK
  • Transmitter Frequency: 433 MHz
  • Encryption: Yes (1-way)
  • Pairing Method: Button Trigger
  • Transmitted Indications: Tamper, Low Battery
  • Tamper: Yes (Cover)
  • LEDs: N/A
  • Battery Type: x1 CR2450 3.0v (600MAh)
  • Battery Life: 8-10 years (x10 per day)
  • Mounting Options: Adhesive
  • Power: 4mA
  • Supervision: Yes (60 minutes heartbeat)
  • Operating Temperature: 32 and 120°F (0 and 49°C)
  • Operating Humidity: 10 - 90% (non-condensing)
  • Weather Resistant: IPX7
  • Freeze Alarm: 5°/35°C
  • Certifications: FCC

GeoWFD Product Installation:


The Installation of the GeoWFD Flood & Freeze Sensor has two key steps:
1. Install both parts of Flood & Freeze sensor.
2. Connect Flood & Freeze sensor to the GeoCP control panel.

Getting your GeoWFD Flood/Freeze Sensor up and running is as simple as press the button, and adding it to your GeoCP panel.

GeoWFD Change Battery:


Please follow the below process.

1. Take the screw cover of the sensor casing out using a screw driver for pulling out the hardware from the plastic casing.
2. Pulling out the screws from the plastic casing to change the battery.
3. Take the front cover out and pull out the cell battery as the picture.
4. Take the cell battery out using a screw driver for pulling out the cell battery as the picture.

GeoWFD Product Compatibility:


  • GeoCP (Part# GEO-CP)
