2GIG-GB100-345 - 2GIG Wireless 345S Series Glassbreak Detector
2GIG-GB100-345 Product Description:
The 2GIG-GB100-345 is a fully supervised, tamper-protected wireless glass break detector engineered for reliable performance in both residential and commercial applications. Designed to provide early detection of intrusion attempts involving glass windows, doors, or display cases, this advanced sensor offers professional-grade protection while minimizing false alarms.
Featuring an intelligent dual-stage acoustic detection algorithm, the 2GIG-GB100-345 listens for both the initial impact "thud" of an object striking glass and the subsequent "crash" of shattering glass. This proven two-step detection method ensures accurate identification of true break events while filtering out common household noises that might otherwise trigger false alarms.
The detector supports both encrypted and non-encrypted communication modes, selectable via an onboard switch. This switchable encryption feature allows security professionals to simplify inventory management - covering both installation types with a single device. The GB100-345 maintains broad compatibility across the 2GIG ecosystem, including 2GIG EDGE, GC Touch, and earlier 2GIG control panels.
With a 15-foot detection radius, 360° maximum horizontal sensing angle, and dual-stage the sensor effectively detects breakage in plate, tempered, laminated, and coated glass, offering comprehensive coverage for perimeter protection. Its flexible wall or ceiling mounting options, adjustable sensitivity settings, and long-lasting battery life (up to 5 years) make it a versatile, low-maintenance choice for modern security systems.
Product Features:
- Dual-stage acoustic detection - recognizes both the "thud" of impact and the "crash" of shattering glass to minimize false alarms.
- Wide detection range - accurately detects glass breakage within a 15-foot (4.6 m) radius.
- Supports multiple glass types - detects plate, tempered, laminated, and coated glass.
- Switchable encryption - toggle between encrypted and non-encrypted modes for installation flexibility.
- Fully supervised wireless communication - provides status monitoring and low-battery alerts.
- Long battery life - up to 5 years of maintenance-free operation.
- Flexible mounting options - designed for wall or ceiling installation.
- Adjustable sensitivity settings - customize detection levels for different environments.
- Broad system compatibility - works with 2GIG EDGE, GC Touch, and legacy 2GIG panels.
- UL Listed Quality - Certified for professional-grade performance, safety, and reliability.
2GIG-GB100-345 Product Specifications:
- Dimensions (D x H): 4.57" x 1.57" (11.6 x 3.99 cm)
- Sensor Type: Single Microphone, Dual Stage Thud, and Crash
- Maximum Horizontal Sensing Angle: 360° for Ceiling Mount or 180° For Wall Mount
- Series: 345S Series
- Transmitter Frequency: 345 MHz
- Transmission Range: Up to 350 ft (106 m) open air (varies by environment)
- Encryption: On/off switchable (encrypted and non-encrypted modes)
- Sensitivity Settings: User-adjustable
- Glass Types Detected: Plate, tempered, laminated, and coated glass
- Detection Range: Up to 15 ft (4.6 m) radius
- Detection Method: Dual-stage acoustic analysis (impact "thud" + shattering "crash")
- Mounting Options: Wall or ceiling
- Compatibility: 2GIG EDGE, GC Touch, GC2e, GC3e, and legacy 2GIG systems or 345 MHz compatible systems
- Code Outputs: Alarm; Alarm Restore; Tamper; Tamper Restore; Supervisory; Low Battery
- Supervision: Fully supervised with tamper and low-battery notifications
- Supervisory Interval: 70 Minutes
- Weight: 0.35 lbs (158g)
- Housing Material: Durable ABS Plastic
- Color: White
- Operating Temperature: 32° to 120°F (0° to 49°C)
- Relative Humidity: 5% to 90%, Non-condensing
- Batteries (Included): Two CR123A 3V or equivalent Lithium batteries
- Battery Life: Up to 5 Years (typical use)
- Warranty: 2 years limited manufacturer's
- Certifications: ETL, FCC, IC
2GIG-GB100-345 Product Compatibility:
- 2GIG EDGE
- GC Touch
- GC2e
- GC3e
- Legacy 2GIG Systems
- Other 345 MHz Compatible Systems
2GIG-GB100-345 Product Includes:
- Glass Break Detector (with Mounting Base)
- Lithium Batteries
- Plastic Wall Anchors with Screws
