Honeywell VISTA 15P Hardwired Security Systems - GeoArm Security®

✓No Contracts    ✓Nationwide Service    ✓Free Tech Support
▼ Honeywell VISTA 15P Hardwired Security Systems ▼

Honeywell VISTA 15P Product Features


Honeywell's versatile VISTA 15P is the ideal choice for any residential installation. VISTA 15P gives you the ability to send alarm signals and upload/download via an Internet Protocol (IP), improving the speed at which information can be delivered to and from the control panel. Hardwired expansion, graphic keypad support, two-wire smoke detectors, scheduling options and a host of end-user and installer features separate the VISTA 15P from all other six-zone panels offers DiYer's the most panel for the dollar.

The VISTA-15P is a high capacity, feature-rich, 32-zones security system that delivers more value to the DiYer. The VISTA 15P comes with 6 on-board hardwired zones, up to 16 hardwired zones with expansion (6 on-board + 16 expansion = 22 total hardwired zones) and up to 26 wireless expansion zones. Also, the VISTA 15P supports up to 8 wireless keyfobs, up to 32 user codes and up to 8 schedules. With the VISTA 15P you can have remote programming capability and graphic keypad support.

In addition, when used with an AlarmNet® broadband internet communicator (7847i), cellular AT&T LTE communicator (LTE-XA), cellular Verizon LTE communicator (LTE-XV), dual-path Verizon IP/LTE communicator (LTE-IV) or dual-path high-security Verizon IP/LTE communicator (LTE-HSV), the VISTA 15P can be installed in premises without traditional TELCO connected lines.

The VISTA 15P security system is backed by Honeywell's 2-year limited manufacturer's warranty and once upgraded with a Honeywell wireless alarm receiver is compatible with the full line of Honeywell 5800-Series wireless security products. GeoArm and Honeywell give you the options you need to fully customize your DiY security system.

Product Features:

  • Six on-board hardwired zones
      - 16 hardwired expansion zones totaling 22
      - 26 wireless expansion zones
  • Supports two graphic touchscreen keypads
  • Eight independent keyfob zones allow wireless keys to be programmed without using any of the 26 zones
  • Eight output devices
      - Relays (Model 4204 Relay Modules, or 4229 Expansion Module)
  • Two low-current on-board trigger outputs
  • 50 Event Log viewable at system keypads with time/date stamp
  • 32 system user codes
  • Two installer configurable zone types allows the installer to "create custom zone types" by assigning all zone attributes
  • Multiple actions on output devices depending on system "state"
      - Turns light off when system arms
      - Turns same lights on when system disarms
      - Flashes same lights when system is in alarm
  • Built-in phone line cut monitor with programmable delay and annunciation options
      - Display on system keypads
      - Trigger local sounders
      - Trigger system bell
  • Supports four-wire and up to 16 two-wire smokes
      - Works with Sentrol CleanMe maintenance signal

Honeywell VISTA 15P End User Features


  • Now viewable on system keypads:
      - Exit countdown
      - Time and date display*
      - Event log*
  • Auto keypad backlighting on entry
  • Keyswitch arming
  • Programmable macro buttons and single-button arming
  • A variety of wireless remote controls for single-button operation
  • User Scheduling
      - Latchkey reports to pagers
      - Auto arm/disarm
      - "User access" time windows
  • Supports up to two numeric pagers
  • VIP Module allows system control from any touchtone phone
  • Chime by Zone

Honeywell VISTA 15P Dealer Features


  • Automatic System Load Shed
      - During extended AC power fail, the system battery will be disconnected to prevent irreversible battery failure. Reduces service calls to replace batteries.
  • Dynamic Signaling
      - Reduces redundant reporting to the GeoArm central station when multiple reporting methods are used; i.e. digital dialer and AlarmNet Radio


*Requires custom alpha keypad

Honeywell VISTA 15P How to Videos:




Do-it-yourself (DiY) home security is emerging as a new trend in the security industry as advances in wireless security system technology have eliminated the need for costly professional on-site hardwired installations. GeoArm is the perfect partner for any home security DIYer considering installing a new wireless security system. With 30 years of professional security installation experience, GeoArm has the technical know-how to make your DiY home security installation as easy and seamless as possible. You can be confident that your DiY security system installation will be backed by a team of expert security professionals. We stand out from our competition by providing you with FREE security system programming with our alarm monitoring services (leave the technical process to the pro's), FREE remote technical support, and FREE do-it-yourself videos!

Once GeoArm receives your order for a VISTA 15P security system, you will receive a confirmation email with a link to an easy VISTA 15P programming form where you will fill out your account information and zone descriptions. Once you have mounted and hardwired all your security devices, GeoArm's central alarm monitoring station will help you do a full system test to ensure your VISTA 15P alarm signals are being sent and received correctly.
