ADC-W114C - Alarm.com Wireless Wi-Fi Smart Chime
Alarm.com ADC-W114C Product Description:
The Alarm.com ADC-W114C Wireless Wi-Fi Smart Chime is designed for use with the ADC-VDB780B battery-powered wireless video doorbell camera. Enhance your Alarm.com video doorbell experience with the Alarm.com ADC-W114C wireless Wi-Fi smart chime. Designed as an affordable and convenient audio accessory for the Alarm.com platform, the ADC-W114C provides customizable audible alerts for doorbell and video events throughout your home or business.
Featuring a compact, antenna-free design, the ADC-W114C plugs directly into a standard wall outlet and connects wirelessly to your existing Wi-Fi router. It can be used to replace a traditional mechanical doorbell chime or to extend audible awareness in locations where camera and doorbell alerts may otherwise be difficult to hear. Through the Alarm.com platform, customers can customize chime tones, adjust volume levels, create chime rules and schedules, and configure audio alerts for supported video events. Remote management and troubleshooting capabilities make it easy to maintain and adjust the chime without complicated on-site configuration.
Installation is simple: plug the ADC-W114C into a standard outlet, pair it with the existing Wi-Fi network, configure your preferred chime rules, and enjoy enhanced audible awareness for your Alarm.com security system.
Product Features:
- Wireless Doorbell Chime - Designed for compatible Alarm.com Video Doorbells
- Compact, Antenna-Free Design - Clean appearance that fits easily into virtually any room
- Simple Plug-In Installation - Connects directly to a standard electrical outlet
- Wi-Fi Connectivity - Pairs wirelessly with the existing router
- Customizable Chime Tones - Select preferred sounds for supported alerts and events
- Adjustable Volume - Set the chime volume to suit the installation environment
- Configurable Chime Rules - Customize when and how the chime responds
- Scheduled Alerts - Configure chime rules and schedules through the Alarm.com platform
- Video Event Audio Alerts - Receive audible notifications for supported video events
- Mechanical Chime Alternative - Can replace a traditional mechanical doorbell chime
- Expanded Audible Coverage - Helps boost audio awareness in camera and video doorbell installations
- Remote Management & Troubleshooting - Conveniently manage supported settings through Alarm.com
Alarm.com ADC-W114C Product Specifications:
Specifications
- Dimensions (H x W x D): 2.4 x 2.4 x 2.4" (6.15 x 6.15 x 6.1cm)
- Wi-Fi Connection: 802.11 b/g/n/ax, 2.4 GHz
- Wi-Fi Security: WPA, WPA2, WPA3
- Bluetooth Version: Bluetooth LE 5.4
- LED Indicators: 1 Multicolor LED
- Buttons: 1 Multi-state button
- Chime: 2 W speaker, 105 dB
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Operating humidity: <90% (non-condensing) RH
Requirements
- Network: 2.4 GHz connection to broadband Internet via router
- Power: 100 - 240 V, 50 - 60 Hz, 0.4 A
LED Reference Guide
- Off: Device powered off
- Blinking red: Device powered on, booting up
- Blinking green: Local connection, no Internet connection
- Solid green: Connected to Alarm.com
- Blinking white: Wi-Fi Access Point Mode + BLE (press and hold button for 3-6 seconds)
- Solid red: No local or Internet connection
- Blinking blue and green: Firmware Update
- Blinking red and green: Factory Reset (press and hold button for 12-15 seconds)
- Blinking yellow: Power Cycle (press and hold button for 9-12 seconds)
Alarm.com ADC-W114C Included Accessories:
- ADC-W114C Alarm.com Wi-Fi Chime
- Quick Start Guide
- Slide-On Plug Adapter (US Blade Included)
