IQGB - IQ Wireless S-Line Glassbreak Detector

IQGB - IQ Wireless S-Line Glassbreak Detector
IQGB - IQ Wireless S-Line Glassbreak Detector
Item# IQGB
List Price: $159.95
Our Price: $106.64
Availability: In Stock
QTY:
Shipping3-5 Business Days
Free 3-5 day ground shipping within the continental United States on orders over $200.

In stock items are shipped ground 1-3 business days from which the date the order was placed. A tracking number will be sent to the email address provided on checkout.

Read the full shipping policy
Returns30-Day Return Window
This item can be returned in its original condition within 30 days of receipt, less a 25% restocking fee of the total invoice price.

Read the full return policy
PaymentSecure Transaction
We work hard to protect your security and privacy. Our payment security system encrypts your information during transaction. We don't share your credit card details. We don't sell your information to others, including affiliates!

For orders identified by our security screening system, we proactively contact customers to verify the purchase and help maintain a safe and secure shopping experience. This extra step taken, prior to shipment, helps us maintain a safe environment by preventing fraudulent activities.

Read the full order processing policy

IQGB Product Description:


The IQGB - IQ Wireless S-Line Glassbreak Detector is an advanced wireless security sensor designed to detect the distinctive sound frequencies associated with breaking glass, providing an additional layer of intrusion protection for residential and commercial properties. Engineered with intelligent acoustic detection technology, the IQ Glass Break continuously listens for the unique sound patterns of shattering glass when the security system is armed, helping identify potential break-in attempts through windows and glass doors. With an effective detection range of up to 25 feet (7.5 meters), a single detector can provide coverage for multiple windows within the same area, making it an ideal security solution for living rooms, bedrooms, offices, storefronts, and other spaces with glass entry points.

Utilizing secure S-Line encryption and 319.5 MHz wireless communication, the IQGB delivers dependable signal transmission while helping protect communications between the detector and compatible IQ security systems. Its backward compatibility with supported legacy 319.5 MHz security systems provides additional installation flexibility for both new security installations and existing system upgrades. The detector integrates with compatible IQ Panels and automatically activates when the security system is armed in either Stay or Away mode, providing reliable glass break protection without requiring separate activation.

The IQ Wireless S-Line Glassbreak Detector incorporates advanced acoustic analysis to distinguish glass-breaking sounds from common household and environmental noises, helping minimize nuisance alarms while maintaining dependable intrusion detection. Its wide-area coverage allows one sensor to monitor multiple glass surfaces, reducing the need for individual detection devices at every window. For optimal performance, the IQGB can be installed on a ceiling or an opposite-facing wall within its specified detection range, providing flexible placement options for larger rooms and open living spaces.

Designed for convenient wireless installation and long-term reliability, the IQGB features battery-powered operation that eliminates the need for complicated wiring or extensive installation work. Its compact, modern appearance blends seamlessly into residential and commercial interiors while delivering an important additional layer of security. Whether protecting a home, office, or business, the IQ Glass Break enhances perimeter security by helping detect attempted forced entry through glass and communicating alarm events to the connected security system for prompt notification and response.

Product Features:

  • Advanced Glass Break Detection - Uses intelligent acoustic sensing technology to identify the distinctive frequencies and sound patterns associated with breaking glass.
  • 25-Foot Detection Range - Detects glass-breaking sounds within an effective range of up to approximately 25 feet (7.5 meters).
  • Secure S-Line Encryption - Incorporates encrypted wireless communication to help protect alarm signals against unauthorized interception and interference.
  • 319.5 MHz Wireless Frequency - Communicates using 319.5 MHz wireless technology for reliable integration with compatible IQ security systems.
  • Legacy System Compatibility - Supports compatible legacy 319.5 MHz security systems, providing additional flexibility for existing installations and system upgrades.
  • Automatic Armed-Mode Activation - Automatically provides glass break detection when the connected IQ security system is armed in Stay or Away mode.
  • Intelligent Acoustic Analysis - Analyzes breaking-glass sound patterns to help identify potential intrusion events quickly and accurately.
  • Wide-Area Glass Protection - One detector can monitor multiple windows or glass doors within its coverage area, reducing the number of sensors required.
  • False Alarm Reduction - Advanced sound recognition helps distinguish actual breaking-glass events from common household noises and environmental sounds.
  • Fast Intrusion Detection - Helps identify potential break-in attempts through windows or other glass surfaces and sends alarm signals to the connected security panel.
  • Flexible Mounting Options - Supports ceiling or opposite-wall installation for effective detection coverage in living rooms, offices, and other open spaces.
  • Wireless Installation - Battery-powered design eliminates the need for hardwired connections, simplifying installation and placement.
  • Long-Life Battery Operation - Designed for dependable battery-powered performance with reduced maintenance requirements.
  • Residential and Commercial Applications - Ideal for protecting homes, apartments, offices, retail stores, and other properties with vulnerable glass entry points.
  • Seamless IQ Panel Integration - Works with compatible IQ security systems to provide coordinated glass break detection as part of a comprehensive intrusion security solution.
  • Compact, Modern Design - Features a discreet white housing that complements a wide variety of residential and commercial interior environments.
  • Enhanced Perimeter Security - Adds an important layer of protection by detecting glass-breaking intrusion attempts that traditional door and window contact sensors may not identify.

IQGB Product Specifications:


  • Dimenstions (L x W x D): 4.2" x 2.7" x 1.2" in (107.5 x 69 x 30 mm)
  • Weight: 105 g (3.7 oz)
  • Color: White
  • Frequency Band: 319.5 MHz
  • Modulation: OOK
  • Communication Protocol: S-Line
  • Battery Type: 3 V Lithium CR123A GP or Panasonic or Duracell only
  • Battery Life: 5 years with typical use at room temperature 25°C (77°F)
    Note: Not evaluated by UL/ULC.
  • Low Battery Threshold: 2.6 V
  • Nominal Operating Voltage: 3 V
  • Operating Temperature: 14°F to 120°F (-10°C to 50°C)
    Note: UL/ULC only evaluated 0°C to 49°C
  • Storage Temperature: -4°F to 140°F (-20°C to 60°C)
  • Relative Humidity: Up to 95% non-condensing
    Note: UL/ULC only evaluated up to 93%
  • Maximum Detection Range: 7.6 m (25 ft) if glass size is minimum 40 x 40 cm (15¾ in. x 15¾ in.)
    6 m(20 ft) if glass size is 30 x 30 cm (12 in. x 12 in.) to 40 x 40 cm (15¾ in. x 15¾ in.)
    For UL/ULC maximum verified range is 6 m (20ft)
  • Glass Type: UL tested on: Plate, tempered, wired, laminated, covered, and sealed insulated
  • Minimum Glass Size: UL tested on: 12 in. x 24 in. (30 x 60 cm)
  • Glass Thickness: UL tested on:
    Plate: 2.4 to 6.4 mm (3/32 in. to 1/4 in.)
    Tempered: 3.2 to 6.4 mm (1/8 in. to 1/4 in.)
    Wired: 6.4 mm (1/4 in.)
    Coated: 3.2 to 6.4 mm (1/8 in. to 1/4 in.) not tested by UL
    Laminated: 3.2 to 6.4 mm (1/8 to 1/4 in.)
    Sealed Insulating: 3.2 to 6.4 mm (1/8 in. to 1/4 in.) not tested by UL
    Note: Laminated and Sealed Insulating glass types are protected only if both plates of the unit are broken.
  • Room Size:
    Not larger than 12 x 12 m (40 x 40 ft)
    Not smaller than 3 x 3 m (10 x 10 ft)
  • Minimum Distance from Glass: 1.5 m (5 ft)
  • Compliance: FCC (319.5 MHz): 47CFR part 15
    ISED (319.5 MHz): RSS-247
    UL/ULC: UL639, ULC-S306

IQGB Product Compatibility:


  • Qolsys IQ Panel 2 (Model Numbers: QS9201-1200-840, QS9202-1200-840)
  • Qolsys IQ Panel 2+ (Model Numbers: QS9201-1208-840, QS9202-1208-840)
  • Qolsys IQ Panel 4 (Model Numbers: IQP4001, IQP4004, IQP4007)
  • Qolsys IQ Hub (Model Numbers: QS9301-1200-840, QS9302-1200-840, QS9307-1200-124)
  • Qolsys IQ4 Hub (Model Number: IQPH051)
  • IQ Panel 5 with 319.5 MHz Daughter Card (Model Number: IQP5017, IQP5018)
  • IQ5 Hub with 319.5 MHz Daughter Card (Model Number: IQH5017, IQH5018)
  • IQ5 NS with 319.5 MHz Daughter Card (Model Number: IQN5017, IQN5018)
