DSC PGP9945E Product Description:

The DSC PGP9945E Wireless PowerG + Door/Window Alarm Contact with Auxiliary Input is a professional-grade security sensor engineered to deliver reliable perimeter protection for residential and commercial alarm systems. Designed for seamless integration with compatible DSC, IQ and Qolsys security platforms, this compact wireless contact monitors the opening and closing of doors, windows, cabinets, gates, and other entry points while utilizing advanced PowerG+ wireless technology for exceptional range, encrypted communication, and dependable performance.

Built with PowerG+ industry-leading two-way wireless communication protocol, the PGP9945E provides extended transmission range, superior signal stability, and enhanced protection against interference or tampering. The device uses military-grade 128-bit AES encryption to help safeguard alarm communications, making it an excellent choice for high-security applications where dependable wireless performance is essential. Its long battery life and intelligent power management reduce maintenance requirements while ensuring consistent operation over extended periods.

One of the standout features of the PGP9945E is its integrated auxiliary input, which allows installers to connect a wired contact or external sensor directly to the device. This added flexibility enables the sensor to protect multiple points simultaneously or incorporate specialized devices such as roller door contacts, floor sensors, or other hardwired security components into a wireless system. The auxiliary input makes the PGP9945E especially valuable for retrofit installations where both wired and wireless devices need to work together efficiently.

The compact, low-profile design allows the contact to blend discreetly into most residential or commercial environments without compromising aesthetics. Installation is quick and straightforward, helping reduce labor time while delivering professional-grade intrusion detection performance. Ideal for use on doors, windows, offices, storefronts, storage facilities, and smart security systems, the DSC PGP9945E Wireless PowerG+ Door/Window Alarm Contact offers a powerful combination of flexibility, security, and reliability for modern alarm installations.

Product Features:

PowerG+ Wireless Technology - Provides long-range, highly reliable encrypted wireless communication between the sensor and alarm panel.
System Compatibility - Designed to work with compatible DSC, IQ and Qolsys security systems.
Door & Window Monitoring - Detects the opening and closing of doors, windows, cabinets, gates, and other protected entry points.
Full Length Magnet - Enhanced reliability with a stronger, more consistent magnetic field.
Auxiliary Input - Includes a built-in auxiliary input for connecting an additional wired sensor or contact device.
User Selectable Aux Input - Reed Switch, Normally Open, Normally Closed, End of Line, Double End of Line, or Triple End of Line.
128-Bit AES Encryption - Uses military-grade encryption to help protect wireless signals from hacking or unauthorized access.
Two-Way Wireless Communication - Enables continuous supervision and reliable signal verification between the sensor and control panel.
Interference Protection - Engineered to resist RF interference and signal jamming for dependable security performance.
Compact Low-Profile Design - Features a sleek and discreet appearance that blends easily into residential or commercial environments.
Easy Installation - Enroll devices faster with battery pull tabs and QR codes. Supports fast and simple installation with minimal wiring requirements.
Over-the-Air Updates - Upgrade sensors and resolve device issues remotely.
Battery Life Reporting - Monitor the exact battery percentage of all devices.
Long Battery Life - Intelligent power management helps maximize battery performance and reduce maintenance needs.
Tamper Protection - Detects unauthorized removal or tampering attempts for added security.
Residential & Commercial Use - Ideal for homes, offices, retail stores, warehouses, and other professional security applications.
Perimeter Security Protection - Helps strengthen intrusion detection by securing vulnerable entry points.
Reliable Wireless Performance - Maintains stable communication even in challenging wireless environments.
Hybrid Security Integration - Allows both wired and wireless security devices to operate together through the auxiliary input.

DSC PGP9945E Product Specifications:

Contact Dimensions (L x W x D): 3.5 x 1.5 x 1.2 in (89mm x 37mm x 30mm)
Weight (including battery and magnet): 53g (1.9 oz)
Frequency Band: 868 to 869 MHz, 912 to 919 MHz
Communication Protocol: PowerG+
Battery Life: 8 years with typical use at room temperature 25°C (77°F) not evaluated by UL/ULC
Battery Type: 3 V Lithium CR123A GP battery only
Nominal Operating Voltage: 3 V
Operating Temperature: 14°F to 131°F (-10°C to 55°C), UL/ULC only verified the range: 32°F to 120°F (0°C to 49°C)
Relative Humidity: Up to a maximum 93% non condensing
Color: White
Auxiliary Input Cable Length: 10 m max, 0.4 mm² (AWG22)
Auxiliary Input EOL Resistor: : 5.6 KΩ
Certifications FCC (912 to 919 MHz): 47CFR part 15.247
Certifications ISED (912 to 919 MHz): RSS-247
Certifications UL/ULC: UL 634, ULC/ORD-C634, UL 985, ULC-S545

DSC PGP9945E Product Documents:

• Datasheet - DSC PGP9945E Wireless PowerG + Door/Window Alarm Contact with Auxiliary Input
• Installation Guide - DSC PGP9945E Wireless PowerG + Door/Window Alarm Contact with Auxiliary Input

DSC PGP9945E Product Compatibility:

DSC PowerSeries Neo Control Panels
DSC PowerSeries Pro Control Panels
Qolsys IQ Panel 4 Control Panels
Qolsys IQ4 Hub Control Panels (Model Number: IQPH054, IQPH058)
Qolsys IQ4 NS Control Panels (Model Number: IQPK047, IQPK048)
Qolsys IQ Pro Control Panels
IQ Panel 5 Control Panels
IQ5 Hub Control Panels
IQ5 NS Control Panels
