Item# SD-15W-ULF

Please Note: The DSC SD-15W-ULF dual tone alarm siren has been discontinued and replaced by the UPG80112 model number.

DSC SD-15W-ULF Product Description:

The DSC SD 15W-ULF is a self-contained, surface-mount, untampered dual-tone interior siren. It is designed for household burglar alarm system accessory and also suitable as an audible signal appliance for fire alarm systems. When power is applied to the alarm siren, it produces an audible steady yelp tone according to the wiring.

DSC SD-15W-ULF Product Specifications:

  • Dimensions: 110mm x 110mm x 55.2mm (H x W x D)
  • Rated Power Supply: 12VDC (Special Application)
  • Operating Current: 380mA
  • Surge Current: 404mA
  • Peak Current: 392mA
  • Sound Pressure Level: 82dB at 10 feet; 90dB at 3 meters
  • Material: ABS

DSC SD-15W-ULF Product Approvals:

  • UL Listed for Household Burglar Alarm System Units (UL1023)
  • UL Listed for Audible Signal Appliances (UL464)
  • CUL Listed for Signal Equipment (CAN/CSA C22.2 no 205)
  • CUL Listed for Audible Signal Devices for Fire Alarm Systems, Including Accessories (CAN/ULC-S525-07)
