PLUNGER-2GIG - Nascom 2GIG-Compatible Wireless Recessed Door/Window Alarm Contact
PLUNGER-2GIG Product Description:
The Nascom PLUNGER-2GIG is a wireless concealed 2GIG-compatible door and window contact that expands the reach of 2GIG security systems. The 2GIG-DW30-345 provides timely notification when doors and windows are opened.
The PLUNGER-2GIG communicates with the 2GIG control panel using the 345 MHz frequency. When the magnet (which is mounted near the sensor) moves away from or closer to the door contact's sensor, signals are transmitted to the control panel.
When mounting the sensor make sure it is within 100 ft (30 m) of the control panel. Although the transmitter may have a range of 350 ft (106.7 m) open air, the sensor location can have a significant effect on range. In open / unobstructed situations, the transmitter range may be greater. In adverse wireless conditions, changing the sensor orientation may lead to improved range. The preferred mounting distance between the sensor and magnet is 1/4 inch, however the maximum gap is 2 inches.
Product Features:
- Sensor enables a wide gap (2 inch) enabling sensing for applications from yard gates, and swimming pool access to detached garages.
- Sends a notification to the alarm panel when a door, gate or window is opened or closed.
PLUNGER-2GIG Product Specifications:
- Wireless Signal Range: 100 ft open air with Wireless Control Panel
- Transmitter Frequency: 345 MHz (crystal controlled)
- Color: White
- Compatibility: 2GIG
- Supervisory Interval: 70 minutes
- Sensor Diameter: 19.05 mm
- Sensor Depth: 0.80" (19.05 mm)
- Magnet Size: Integrated
- Circuit Configuration: Closed Loop
- Contact Diameter: 0.8"
- Contact Length: 0.3" (8.382 mm)
