TL265GS - DSC Alexor Dual-Path Alarm Communicator (Powered by Connect24)

TL265GS - DSC Alexor Dual-Path Alarm Communicator (Powered by Connect24)
TL265GS - DSC Alexor Dual-Path Alarm Communicator (Powered by Connect24)
Item# TL265GS

Please Note: The DSC Alexor TL265GS dual-path alarm communicator has been discontinued without replacement.

DSC TL265GS Product Description:


The DSC TL265GS is a wireless 2G cellular unit that connects the alarm control panel to the existing internet (IP) connection, and in the event of a signal failure, automatically backs up to the GSM cellular network to report alarm signals directly to GeoArm's Central Station receiver. The DSC TL265GS uses this dual path alarm communication method to ensure reliable alarm communications that are both low-cost and high-speed. This dual path communication reduces the need for a dedicated phone line and any concerns over the internets reliability for commercial applications. The DSC TL265GS is compatible with the DSC Alexor wireless security system and communicates using the SIA format. Do not put your home security on the line. As more and more homes or businesses move away from traditional phone lines, towards VoIP (Voice over IP) or mobile phones, alternate delivery methods for alarm communication must be explored for security systems. The DSC TL265GS dual path alarm communicator is an ideal solution for both business and home security with either no dedicated phone line in place and for those who are concerned with telephone line tampering. Get maximum protection with dedicated wireless communication to ensure all your alarms and status messages get through to GeoArm's central alarm monitoring station.

Millions of American homes and families rely on security systems for protection, but no matter how many locks, sensors or detectors you have, your entire system depends on one fine line between safety and danger - your phone line. Wireless alarm communications eliminate that vulnerability and provide you with the protection and dedication you need. With the widespread use of cell phones these days, most people only use their land line for their alarm communication. If you are one of these people, eliminate that phone line and use the money saved to invest in a DSC TL265GS unit. Over the life of your security system this will actually save you money!

Product Features:

  • Primary Internet backed up by GSM/GPRS cellular alarm communicator
  • Fully redundant Internet and GSM/GPRS dual-path alarm communication
  • Compatible with DSC Alexor wireless control panel
  • Panel remote uploading/downloading support via GSM/GPRS
  • Individual periodic test transmission via GSM/GPRS
  • Supervision heartbeats via GSM/GPRS and Internet
  • 128-bit AES encryption over GSM/GPRS and Internet
  • Integrated call routing
  • Full event reporting
  • SIA format
  • PC-Link connection
  • Signal strength and trouble display
  • Remote activating, initializing and programming through Connect 24
  • Quad-Band: 850MHz, 1900MHz, 900MHz and 1800MHz
  • SIM card (included)
  • Approvals: UL, ULC, FCC/IC, PTCRB
  • UL standard & encrypted line security
  • ULC passive or active line security levels
  • Backed by DSC's 1-year limited manufacturer's warranty

DSC TL265GS Product Specifications:


  • Dimensions (L x W x D): 100 x 150 x 19.05 (mm) or 3.937 x 5.875 x 0.75 (in)
  • Weight: 0.172lbs (78g)
  • Input Voltage: 10-13.8V (from the panel PC-Link header)
  • Current Draw: 100mA at 12V (400mA during the GSM transmission)
  • Operating Environment: 40° to 104°F (5° to 40°C)
