The Honeywell 5804BD is a four-button wireless key that permits an alarm system to be controlled remotely. It is a bidirectional device, which means that it can send a command to the control, such as to arm or disarm, and can also receive status back from the control, which is indicated by two bi-color status LEDs and a piezoelectric sounder.
Each button can be programmed for any zone response type by using the control's transmitter "enroll" mode. Typical use is for arming, disarming, panic, and output relay operation. The 5804BD must be used in conjunction with a bidirectional 5800 tranceiver (6150RF, 6160RF, 5883H, etc.) or a combination of 5800TM (Transmitter Module) and 5881 Family RF Receiver. The unit is powered by two replaceable batteries designed to provide several years of operation.
The expected battery life is a function of the device environment, usage and type. Ambient conditions such as high humidity, high or low temperatures, or large temperature fluctuations may reduce the expected battery life. This device will report a low battery condition to the control panel as a trouble condition, when the batteries need to be replaced. In addition the yellow LED will not flash when a button is pressed. However, if the device is unused for a long period of time, it may fail to operate as expected. Regular testing and maintenance will keep the system in good operating condition for the lifetime of the product.
Keyfob Dimensions: 4" H x 2" W x 5/8" D
Belt Dimensions: 4.1" H x 2.2" W x 0.8" D
Transmitter Dimensions: 3.9" H x 2.0" W x 0.69" D
Operating Temperature: -10°F to 120°F (-12°C to 149°C) Indoor use only
Battery: Maxell CR2430 or Duracell DL2430
Visual and audible system status feedback (requires 5800TM Transmission Module)
Four completely programmable buttons
Remote operation of appliances lights, and garage doors
Two-button operation for panic applications
Includes user replaceable, long-life lithium batteries
